CCM682
The CCM682 is a two-way in-ceiling speaker from the Performance series, built around a 25mm aluminium dome tweeter and a 200mm (8in) Aramid fibre bass/midrange driver. It suits custom-install and home-theatre or multiroom projects where a ceiling-mounted speaker is needed.
- Two-way in-ceiling speaker, Performance series
- 25mm (1in) aluminium dome tweeter with Nautilus swirl loading
- 200mm (8in) blue Aramid fibre bass/midrange cone
- Offered in White
- Manual, info sheet and drawing available
- Largest of four Performance in-ceiling models
Photos
5Annonces
Pas encore d’annonce pour ce modèle
Quand quelqu’un vendra un CCM682, les annonces et l’historique des ventes s’afficheront ici.
Vendre le mêmeDescription
The CCM682 is the largest of the four in-ceiling models in the Performance range, sitting above the CCM662, CCM683 and CCM684. It is a two-way design that pairs a dedicated tweeter with a separate bass/midrange driver for ceiling installation.
The tweeter is a 25mm (1in) aluminium dome with a Nautilus swirl-loaded rear, while the bass/midrange unit is a 200mm (8in) cone made from blue Aramid fibre. The range is described as having strong power-handling characteristics.
The speaker is supplied in white and is listed as a new-condition item. A manual, an info sheet and a drawing are available for installers, and the range is aimed at custom installation work, where an installer would plan the cut-out and wiring.
Spécifications
- Marque
- Bowers & Wilkins
- Modèle
- CCM682
- Catégorie
- Hi-Fi et audio maison › Enceintes
Audio
- Configuration
- Two-way in-ceiling speaker
- Tweeter
- 1x ø25mm (1in) Nautilus™ swirl loaded aluminium dome tweeter
- Bass/midrange driver
- 1x ø200mm (8in) blue Aramid Fibre cone bass/midrange driver
- Number of drive units
- 2
Physical
- Series
- Performance
- Type
- In-ceiling speaker
- Finish
- White
- Condition
- New
Documentation
- Manual
- Available
- Info sheet
- Available
- Drawing
- Available
