Ci200TRB
In-ceiling subwoofer from KEF's architectural range, built around a 200 mm (8 in.) ultra-thin T Series woofer. It suits installations with very little mounting depth, such as narrow ceiling or wall cavities in apartments and home theatres.
- 200 mm (8 in.) ultra-thin T Series subwoofer driver
- Mounting depth from surface of 59 mm (2.32 in.)
- Passive response 42 Hz-120 Hz; 32 Hz-120 Hz with KASA500
- Pairs with Ci160TR and Ci160TS speakers in passive mode
- Stereo mode 2 x 8 Ohm; mono mode 16 Ohm
- Cut-out 240 x 240 mm; weight 1.7 kg
Photos
8Annonces
Pas encore d’annonce pour ce modèle
Quand quelqu’un vendra un Ci200TRB, les annonces et l’historique des ventes s’afficheront ici.
Vendre le mêmeDescription
The Ci200TRB is a shallow-mount 200 mm (8 in.) subwoofer that uses a subwoofer version of KEF's ultra-thin T Series woofer driver. It needs under 59 mm of mounting depth, so it fits in tight ceiling or wall spaces where a conventional bass unit would not.
It can run in two ways. In passive mode it extends the low end of KEF's Ci160TR round or Ci160TS square speakers, with a recommended amplifier power of 10-125 W and a frequency response of 42 Hz-120 Hz. In active mode it is driven by the KEF KASA500 System Amplifier, which lowers the response to 32 Hz-120 Hz and gives the output expected of a subwoofer in a home theatre.
The nominal impedance is 2 x 8 Ohm in stereo mode or 16 Ohm in mono mode, and sensitivity is 87 dB (2.83 V / 1 m). The grille-fronted unit measures 290 x 290 mm with a 240 x 240 mm cut-out and weighs 1.7 kg.
Vidéo
Spécifications
- Marque
- KEF
- Modèle
- Ci200TRB
- Catégorie
- Hi-Fi et audio maison › Enceintes
Audio
- Frequency response (passive)
- 42Hz-120Hz
- Frequency response (with KASA500)
- 32Hz-120Hz
- Sensitivity
- 87dB (2.83V/ 1m)
- Drive units
- LF: 200mm (8 in.)
Power
- Nominal impedance (stereo mode)
- 2 x 8 Ohm
- Nominal impedance (mono mode)
- 16 Ohm
- Recommended amplifier power (passive)
- 10-125W
- Recommended amplifier power (active)
- KASA500
Installation
- Cut-out dimensions (H x W)
- 240 mm x 240 mm (9.45 in. x 9.45 in.)
- Mounting depth from surface
- 59mm (2.32 in.)
Physical
- Product external dimensions (H x W x D)
- 290 mm x 290 mm x 63 mm (11.42 in. x 11.42 in. x 2.48 in.)
- Net weight
- 1.7kg (3.75 lbs)
