CD-200iL
A 2U rack-mount professional CD player with a built-in iPod dock that accepts both 30-pin and Lightning connectors. It suits installations and venues that need CD, data-disc and iPod playback from one unit. The model has been discontinued.
- Built-in 30-pin and Lightning iPod dock with charging
- Plays CD-DA and data CDs (WAV/MP3/MP2)
- RCA analog plus coaxial and optical S/PDIF outputs
- +/-14% pitch control and 10-second shockproof memory
- 2U EIA rack-mount size, 5.2 kg
- Wireless remote with 10-key included
Photos
6Annonces
Pas encore d’annonce pour ce modèle
Quand quelqu’un vendra un CD-200iL, les annonces et l’historique des ventes s’afficheront ici.
Vendre le mêmeDescription
The CD-200iL plays audio CDs and data CDs containing WAV, MP3 or MP2 files from a TEAC-built drive designed for audio. A 10-second shockproof memory guards against skipping from vibration. CD text and ID3 tags are shown on the display. Playback modes include continuous, shuffle and program, with single and all-track repeat. Data discs also support folder playback, folder skipping and folder repeat. A pitch control of +/-14% is available, and an intro check function plays the first 10 seconds of each track in turn.
The front dock takes iPods and iPhones through a 30-pin or Lightning connector without a conversion cable. The dock carries audio output, transport control and charging, and the player's controls can handle album skip, repeat and playback mode on the connected device. A stereo mini jack on the front panel accepts other portable audio sources, and a 6.3 mm headphone output is provided.
Outputs on the rear are unbalanced RCA analog plus coaxial and optical S/PDIF digital. The chassis is 2U in EIA rack-mount size, and a wireless remote with a 10-key pad is supplied.
Vidéo
Spécifications
- Marque
- Tascam
- Modèle
- CD-200iL
- Catégorie
- Hi-Fi et audio maison › Lecteurs
Playback
- Playback media
- CD, CD-ROM, CD-R, CD-RW (12cm/8cm)
- CD-DA format
- Stereo, 44.1kHz, 16bit
- WAV format
- Stereo, 8k / 16k / 32k / 11.025k / 22.05k / 44.1k / 12k / 24k / 48kHz, 8/16bit
- MP2 format
- Stereo, 32k / 44.1k / 48kHz, 32kbps - 384kbps
- MP3 format
- Stereo, 32k / 44.1k / 48kHz, 32kbps - 320kbps, VBR
- Pitch control
- +/-14%
Inputs
- Analog audio input connector
- 3.5mm (1/8") stereo mini jack
- Input impedance
- 22k ohms
- Nominal input level
- -20dBV
- Maximum input level
- -4dBV
Outputs
- Analog output connector
- RCA pin-jack (unbalanced)
- Analog output impedance
- 200ohms
- Nominal output level
- -10dBV (0.32Vms)
- Maximum output level
- +6dBV (2.0Vms)
- Coaxial digital output
- RCA pin-jack, 75ohm, IEC60958-3 (S/PDIF)
- Optical digital output
- TOS (JEITA RC-5720C), IEC60958-3 (S/PDIF)
- Headphone connector
- 6.3mm (1/4") stereo phone jack
- Headphone maximum output
- 20mW + 20mW or more (THD+N 0.1% or less, into 32ohms)
Audio
- Frequency response
- 20Hz-20kHz, +/-1dB (playback, JEITA)
- Distortion
- 0.01% or less (playback, JEITA)
- S/N ratio
- 90dB or more (playback, JEITA)
- Dynamic range
- 90dB or more (playback, JEITA)
- Channel separation
- 90dB or more (playback, JEITA)
Power
- Power supply
- AC120V, 60Hz (U.S.A./Canada); AC230V, 50Hz (U.K./Europe); AC240V, 50Hz (Australia)
- Power consumption
- 15W
Physical
- Dimensions
- 481(W) x 94.5(H) x 298(D)mm
- Weight
- 5.2kg (11.5 lb)
- Operating temperature
- 5˚C - 35˚C
- Inclination of installation
- 5˚ or less
Software
- Compatible OS
- iOS 10, iOS 9
In the box
- Standard accessories
- Wireless remote controller (RC-CD200iL), AA battery x2, Rack mounting screw, Warranty card, Owner's manual
