DP-03
The DP-03 is an 8-track digital portastudio that records to SD or SDHC cards, aimed at home and project-studio musicians who want a compact multitrack recorder. It has been discontinued and replaced by the DP-03SD.
- 8-track recorder using SD (64MB-2GB) or SDHC (4GB-32GB) cards
- 44.1kHz / 16-bit recording
- Built-in omnidirectional stereo microphone
- Two inputs with XLR and 1/4" TRS; guitar-capable TRS on input A
- USB 2.0 mass storage for file transfer to a computer
- Discontinued; replaced by the DP-03SD
Photos
5Annonces
Pas encore d’annonce pour ce modèle
Quand quelqu’un vendra un DP-03, les annonces et l’historique des ventes s’afficheront ici.
Vendre le mêmeDescription
The DP-03 is a compact multitrack recorder that stores audio on SD cards (64MB to 2GB) or SDHC cards (4GB to 32GB). It records at 44.1kHz and 16-bit resolution and has a built-in omnidirectional stereo microphone. Two input channels, A and B, each offer an XLR connector and a 1/4" TRS jack. The TRS input on channel A also accepts a guitar signal.
On the processing side it provides a high and low band EQ (±12dB), six reverb presets (Hall 1, Hall 2, Room, Studio, Plate 1, Plate 2), and a set of mastering effects: EQ, a compressor with multi-band and single-band presets, and a Normalize function. A metronome with a tempo range of 20 to 250 and a chromatic and oscillator tuner are built in.
Outputs are a stereo RCA line output and a 3.5mm headphone jack. A mini-B USB 2.0 port works as a mass storage device for transferring files to Windows or Mac computers, and a 2.5mm remote jack is provided. The unit runs from the supplied AC adapter and weighs 1.8kg.
Vidéo
Spécifications
- Marque
- Tascam
- Modèle
- DP-03
- Catégorie
- Studio › Enregistreurs
Recording
- Recording media
- SD card (64MB to 2GB), SDHC card (4GB to 32GB)
- MTR partition
- TASCAM original
- FAT partition
- FAT32
- Built-in mic
- Omni directional, Stereo
- Sampling frequency
- 44.1kHz
- Quantization bit rate
- 16bit
Inputs
- Input A XLR connector
- XLR-3-31 (1: GND, 2: HOT, 3: COLD), balanced
- Input A XLR impedance
- 2.4k ohms
- Input A XLR nominal / max level
- -16dBu / 0dBu
- Input A TRS connector
- 6.3mm (1/4") TRS jack, balanced
- Input A TRS impedance
- 10k ohms or more (MIC/LINE); 1M ohms (GUITAR)
- Input A TRS nominal / max level
- +4dBV / +24dBV
- Input B XLR connector
- XLR-3-31 (1: GND, 2: HOT, 3: COLD), balanced
- Input B TRS impedance
- 10k ohms or more
Outputs
- Line output (L/R)
- RCA pin jack, unbalanced
- Line output nominal / max level
- -10dBV / +6dBV
- Phones
- 3.5mm (1/8") stereo mini jack, 40mW+40mW (32 ohms loaded)
Connectivity
- Remote
- 2.5mm TS jack
- USB
- Mini-B, USB 2.0 High Speed mass storage class
Effects and tools
- EQ Hi
- +/-12dB, 1.7kHz to 18kHz
- EQ Lo
- +/-12dB, 32Hz to 1.6kHz
- Reverb presets
- 6 (Hall1/Hall2/Room/Studio/Plate1/Plate2)
- Mastering compressor
- Threshold, Ratio, Level; 9 multi-band and 4 single-band presets
- Metronome
- Tempo 20 to 250; Beat 1 to 12
- Tuner
- Chromatic C3 to B5; Oscillator C3 to B5, 435Hz to 445Hz
Audio
- Frequency response
- 20Hz to 20kHz +1/-3dB (INPUT to LINE OUT)
- S/N ratio
- 90dB or more (INPUT to LINE OUT)
- Distortion
- 0.01% or less (INPUT to LINE OUT)
Power
- Power
- Dedicated AC adapter (TASCAM PS-1225L, included)
- Power consumption
- 10W (when phantom power supplying)
Physical
- Dimensions
- 290(W)×54.1(H)×207.2(D)mm / 11.42"(W)×2.13"(H)×8.16"(D)
- Weight
- 1.8kg
In the box
- Accessories
- 2GB SD card, AC adapter (PS-1225L), Warranty card, Owner's manual
