LA-80MKII
Eight-channel line converter that changes unbalanced RCA inputs to balanced XLR outputs. It suits installed audio systems that need to link consumer-level and professional equipment, such as conference rooms, classrooms and auditoriums.
- 8 channels, unbalanced RCA in to balanced XLR out
- ±12 dB trim control for level matching
- Signal-present LED on each channel
- Input level +4 dBu/-20 dBu selectable per channel
- Per-channel ground lift plus All Lift switch
- 19-inch rack case, 1.74 in (44 mm) high, 3 kg
Photos
6Annonces
Pas encore d’annonce pour ce modèle
Quand quelqu’un vendra un LA-80MKII, les annonces et l’historique des ventes s’afficheront ici.
Vendre le mêmeDescription
The LA-80MKII is a rack-mount line amplifier with eight independent channels, each taking an unbalanced RCA input and providing a balanced XLR output. It is a revised version of an earlier line amplifier design, and sits alongside the LA-81MKII, which does the reverse job of converting balanced signals to unbalanced.
Every channel has a trim control with a range of ±12 dB for matching levels between connected devices, plus a signal-present LED that helps when designing a system or tracing faults. Input level can be set per channel to +4 dBu or -20 dBu, with a -10 dBV output level. Each channel also has its own ground lift switch, and a separate All Lift switch removes the ground connections for the whole unit.
The unit is housed in a black 19-inch rack case with a standard chassis depth, which is meant to make wiring easier. It has an earth terminal on the chassis. This model has been discontinued by the maker.
Spécifications
- Marque
- Tascam
- Modèle
- LA-80MKII
- Catégorie
- Studio › Préamplis et outboard
Inputs
- Channels
- 8
- Unbalanced connectors
- RCA
- Input level
- +4dBu/-20dBu, selectable per channel
Outputs
- Balanced connectors
- XLR
- Output level
- -10dBV, selectable per channel
Audio
- Trim control
- +/- 12dB
- Signal indicator
- Signal Present LED per channel
- Conversion
- Unbalanced to balanced
Grounding
- Ground Lift
- Switch per channel
- All Lift
- Disables ground connections for entire unit
- Earth terminal
- Yes
Physical
- Dimensions (W x H x D)
- 19" x 1.74" x 11" (482 x 44 x 280 mm)
- Weight
- 6.6 lbs (3 kg)
- Mounting
- 19" rack case
- Finish
- Black
