M-164UF
16-channel analog mixer with six XLR mic inputs, five stereo line inputs, built-in effects and a 16-out, 2-in USB 2.0 audio interface. Suited to live bands, home recording and installations; the model has been discontinued.
- 16 inputs: 6 XLR mic and 5 stereo line
- Phantom power and hipass filter on mic inputs
- RIAA phono preamp on channels 9-10 (RCA)
- Stereo effects processor with 16 presets
- USB 2.0 interface: 16 out, stereo return, 96kHz/24-bit
- Includes Cubase LE4 recording software
Photos
8Annonces
Pas encore d’annonce pour ce modèle
Quand quelqu’un vendra un M-164UF, les annonces et l’historique des ventes s’afficheront ici.
Vendre le mêmeDescription
The M-164UF is the top model of the M-164 series. It combines a 16-channel mixing section with a stereo effects processor and a USB 2.0 audio interface. Six mic channels have XLR inputs with phantom power, a hipass filter and a 3-band EQ, while five stereo line inputs make up the rest of the 16 inputs. Channels 9-10 offer RIAA phono preamps on RCA inputs for turntables.
Output routing includes main and sub busses on 1/4" outputs, separate stereo and mono main and aux outputs, and two aux sends that can feed monitors or effects. A built-in meter bridge is part of the layout. The effects processor provides 16 presets covering reverb, delay, chorus and other effects.
The USB 2.0 interface sends 16 outputs to the computer and returns a stereo signal from it at up to 96 kHz / 24-bit, so every input can be recorded to its own track. It works with Mac OS X and Windows, and Cubase LE4 recording software is included.
Vidéo
Spécifications
- Marque
- Tascam
- Modèle
- M-164UF
- Catégorie
- Sonorisation live › Tables de mixage live
Inputs
- Channels
- 16-channel mixing
- Microphone inputs
- 6 XLR with phantom power and hipass filter
- Stereo line inputs
- 5
- Phono preamp
- RIAA on channels 9-10 (RCA)
Outputs
- Busses
- Sub and Main output busses (1/4" outputs)
- Main and aux outputs
- Separate stereo and mono outputs (1/4")
- Aux sends
- 2 (1/4" outputs)
Audio
- EQ, mic channels 1-6
- 3-band
- EQ, line channels 7-10
- 2-band
- EQ, main output
- 2-band
- Effects processor
- Stereo, 16 presets (reverb, delay, chorus and others)
- Metering
- Built-in meter bridge
Connectivity
- USB interface
- USB 2.0 audio interface
- USB outputs to computer
- 16
- USB return from computer
- Stereo
- Sample rate / bit depth
- 96kHz / 24-bit
Software
- Supported OS
- Mac OS X, Windows XP, Windows Vista
- Driver
- V2.07rc1 (2016-03-28)
- Bundled software
- Cubase LE4 48-track recording workstation
