MD-301mkII
The MD-301mkII is a rack-mountable MiniDisc recorder with balanced XLR, unbalanced RCA and optical digital connections, aimed at PA installations and studios. It has since been discontinued by the maker.
- 2U rack-mountable MiniDisc recorder
- Balanced XLR and unbalanced RCA analog I/O
- Optical SPDIF I/O plus front panel optical input
- Front panel PS/2 keyboard port for naming and control
- 74 min stereo / 148 min mono record modes
- RC-32 wireless remote included
Photos
7Annonces
Pas encore d’annonce pour ce modèle
Quand quelqu’un vendra un MD-301mkII, les annonces et l’historique des ventes s’afficheront ici.
Vendre le mêmeDescription
The MD-301mkII records to and plays back from MiniDisc in a 2U rack-mount chassis. Analog connections are balanced XLR and unbalanced RCA, and digital transfers use optical SPDIF in and out. A second optical input on the front panel makes it easy to connect portable players without reaching around to the back of the rack.
Recording runs in either a 74-minute stereo mode or a 148-minute mono mode, which allows almost two and a half hours of continuous recording on one disc. Playback offers program and shuffle modes plus a timer play function, and the track order can be changed through full TOC editing. Audio coding is ATRAC v2, rev 4.5.
A PS/2 keyboard port on the front panel accepts an ordinary PC keyboard for naming tracks, editing the TOC and controlling the unit. A headphone output with level control is provided, and the RC-32 wireless remote is supplied in the box.
Vidéo
Spécifications
- Marque
- Tascam
- Modèle
- MD-301mkII
- Catégorie
- Autre
Inputs
- Analog inputs
- Balanced XLR and unbalanced RCA
- Digital input
- SPDIF optical
- Front panel digital input
- SPDIF optical
Outputs
- Analog outputs
- Balanced XLR and unbalanced RCA
- Digital output
- SPDIF optical
- Headphone output
- Yes, with level control
Connectivity
- Keyboard port
- PS/2 (front panel)
- Remote control
- RC-32 wireless remote
Audio
- Recording time (stereo)
- 74 minutes
- Recording time (mono)
- 148 minutes
- Codec
- ATRAC v2, rev 4.5
- Media
- MiniDisc
Playback and editing
- Play modes
- Program and shuffle
- Timer play
- Yes
- TOC editing
- Complete, including changing track order
Physical
- Format
- 2-U rack mountable
In the box
- Remote
- RC-32 wireless remote
