Porta02mkII
A 4-track cassette recorder with a built-in mixer, aimed at beginner musicians, songwriters and music educators. It records, overdubs and mixes down to standard cassette, and is no longer in production.
- 4-track cassette recorder with integrated mixer
- 2 mic/line input channels
- Standard 1 7/8 ips tape speed
- Records 2 tracks simultaneously
- Level and pan controls on each of 4 mixer channels
- Headphone output with level control
Photos
8Annonces
Pas encore d’annonce pour ce modèle
Quand quelqu’un vendra un Porta02mkII, les annonces et l’historique des ventes s’afficheront ici.
Vendre le mêmeDescription
The Porta02mkII combines a four-channel mixer and a cassette multitrack recorder in one unit. It runs at the standard 1 7/8 ips cassette speed, so tapes can be played back on ordinary consumer stereo cassette decks. The workflow covers recording, overdubbing and mixing down to a standard cassette.
Two mic/line input channels feed the recorder, and two tracks can be recorded at the same time. The four-channel mixer has level and pan controls on every channel, so the balance and stereo position of each track can be set during mixdown.
Monitoring is through a headphone output with its own level control. Documentation listed for the model includes an owner's manual and a beginner's guide to recording. The manufacturer lists the model as discontinued.
Vidéo
Spécifications
- Marque
- Tascam
- Modèle
- Porta02mkII
- Catégorie
- Studio › Enregistreurs
Recorder
- Type
- 4 track integrated mixer/cassette multitrack recorder
- Number of tracks
- 4
- Tape speed
- Standard 1 7/8 ips
- Simultaneous recording
- 2 tracks
- Tape format
- Standard cassette
- Cassette deck compatibility
- Consumer stereo cassette decks
Inputs
- Mic/line input channels
- 2
Mixer
- Mixer channels
- 4
- Channel controls
- Level and pan on each channel
Outputs
- Headphone monitor output
- Yes, with level control
Functions
- Record
- Yes
- Overdub
- Yes
- Mixdown to cassette
- Yes
Documentation
- Owner's manual
- Porta02mkII Owner's Manual (2007-07-17, 504.54 KB)
- Guide
- A Beginner's Guide to Recording (2007-07-15, 2.60 MB)
- Product status
- Discontinued
