TU-690
The TU-690 is a 2U rack-mountable AM/FM radio tuner with a large display, a 10-key pad for direct frequency entry and 60 station presets. It suits studios, broadcast racks and installations that need a simple radio source. The model has been discontinued.
- 2U rack-mountable AM/FM tuner
- 30 AM and 30 FM presets (60 total)
- 10-key pad for direct tuning and presets
- Sleep timer
- AM and FM antenna connections on rear panel
- IR remote and 150 to 75 ohm adapter included
Photos
8Annonces
Pas encore d’annonce pour ce modèle
Quand quelqu’un vendra un TU-690, les annonces et l’historique des ventes s’afficheront ici.
Vendre le mêmeDescription
The TU-690 is a basic AM/FM tuner built in a 2U rack-mount chassis. Stations can be tuned by typing a frequency on the 10-key pad, or recalled from memory. The unit stores 30 AM and 30 FM presets, 60 in total. The display is large enough to be read from across a room, and a sleep timer is included.
Antenna connections for both AM and FM are on the rear panel. The supplied antennae can be attached, or a larger building-mounted antenna can be used in their place. A 150 to 75 ohm adapter is provided to match the antenna cabling.
An IR remote control comes with the tuner. Documentation published for the model includes an owner's manual, technical documentation, a design specification and an IR remote controller code list. The manufacturer lists the TU-690 as discontinued.
Vidéo
Spécifications
- Marque
- Tascam
- Modèle
- TU-690
- Catégorie
- Hi-Fi et audio maison › Autre Hi-Fi
Tuner
- Bands
- AM/FM
- AM presets
- 30
- FM presets
- 30
- Total presets
- 60
- Direct tuning
- 10-key pad
- Sleep timer
- Yes
Connectivity
- Antenna connections
- AM and FM
- Antenna location
- Rear panel
- Antenna options
- Included antennae or larger building-mounted antenna
Physical
- Format
- 2-U rack-mountable
- Display
- Large, clear display
In the box
- Antennae
- AM and FM antennae included
- Antenna adapter
- 150 to 75 Ohm adapter
- Remote
- IR remote
Documentation
- Owner's manual
- TU-690 Owner's Manual (2007-07-20)
- Technical documentation
- TU-690 Technical Documentation (2008-02-28)
- Design specification
- TU-690 Design Specification (2007-07-20)
