US-125M
Compact USB-powered audio interface with a built-in mixer that combines mic, guitar, RCA line and computer audio into one stereo feed for the computer. Aimed at live streaming and home recording; it can also run as a basic stand-alone mixer. Discontinued.
- Mixer-style USB 2.0 interface with four inputs, each with its own level control
- Mic input on rear XLR/TRS or front 3.5 mm mini jack, with switchable limiter
- Guitar input on 1/4" jack and stereo RCA line input
- Zero-latency hardware monitoring; RCA monitor and headphone outputs
- 16 bit/48 kHz audio over standard Windows (WDM) and Core Audio drivers
- USB bus-powered, aluminum case, usable as a stand-alone mixer
Photos
6Annonces
Pas encore d’annonce pour ce modèle
Quand quelqu’un vendra un US-125M, les annonces et l’historique des ventes s’afficheront ici.
Vendre le mêmeDescription
The US-125M is a USB 2.0 audio interface with a four-channel mixer section. A microphone input, a guitar input, a stereo RCA line input and the stereo playback signal from the computer each have their own level control. The combined mix is sent back to the computer over USB, which suits streaming and broadcasting over the internet.
The microphone can be connected either to a balanced XLR/TRS combination of jacks on the rear or to an unbalanced 3.5 mm mini jack on the front, which supplies plug-in power. A switchable limiter and a signal/overload indicator help manage input levels. Monitoring is handled in hardware without latency, through an RCA monitor output and a 3.5 mm headphone output that has its own level control.
The unit draws power from the USB bus, so no AC adapter is needed, and it works with the standard Windows (WDM) and Mac OS X (Core Audio) drivers without a dedicated driver install. Audio resolution is up to 16 bit/48 kHz. The housing is aluminum. The mixer can also be used without a computer as a simple stand-alone mixer.
Vidéo
Spécifications
- Marque
- Tascam
- Modèle
- US-125M
- Catégorie
- Studio › Interfaces audio
Inputs
- Mic in (rear, XLR)
- XLR-3-31, balanced
- Mic in (rear, TRS)
- 6.3 mm (1/4") TRS jack, balanced
- Mic in (front)
- 3.5 mm (1/8") stereo mini jack, unbalanced, plug-in power
- Mic input impedance
- 2.2k ohms
- Mic nominal input level
- -64 dBu ±3 dB to -44 dBu ±3 dB
- Mic maximum input level
- -28 dBu ±3 dB
- Instrument in
- 6.3 mm (1/4") TS jack, unbalanced
- Instrument input impedance
- 1M ohms
- Instrument maximum input level
- +6 dBV
- Line in
- RCA pin jack, unbalanced
- Line nominal input level (input min)
- -15 dBV
- Line maximum input level
- +21 dBV
Outputs
- Line out
- RCA pin jack, unbalanced
- Line out impedance
- 200 ohms
- Line out maximum level
- +3 dBV ±2 dB (+1.41 Vrms)
- Headphones out
- 3.5 mm (1/8") stereo mini jack
- Headphones maximum output
- 15 mW + 15 mW (32 ohms loaded)
Connectivity
- USB connector
- USB B type, 4-pin
- USB format
- USB 2.0 High Speed / USB 2.0 Full Speed (USB 1.1 equivalent, 12 MHz)
Audio
- Sampling frequencies
- 32/44.1/48 kHz
- Bit depth
- 16 bit
- Frequency response
- 20 Hz to 20 kHz, ±2 dB
- A/D dynamic range
- 89 dB
- A/D S/N ratio
- 89 dB
- A/D channel separation
- 85 dB
- D/A dynamic range
- 93 dB
- D/A S/N ratio
- 96 dB
- D/A channel separation
- 92 dB
Software
- Windows driver
- WDM (standard Windows driver)
- Mac driver
- Core Audio (standard Macintosh driver)
Power
- Power
- USB bus powered
- Power consumption
- 1 W
Physical
- Dimensions (W × H × D)
- 150 × 40.6 × 122 mm
- Weight
- 500 g
- Operating temperature
- 5 to 35 °C
In the box
- Included
- USB cable (1.5 m), warranty card, Quick Start Guide, owner's manual
