US-224
Discontinued USB 1.1 audio/MIDI interface and DAW control surface from Tascam and Frontier Design Group. It gives home and portable studio users two channels of 24-bit audio, 16-channel MIDI I/O and hands-on faders and transport controls.
- 2 in / 2 out audio, up to 24-bit / 48 kHz
- 16-channel MIDI In/Out
- Four faders, transport/locate controls, data wheel
- USB bus-powered, Mac and Windows compatible
- Includes Cubase LE and GigaStudio 3 LE
- Discontinued; replaced by US-2x2HR
Photos
8Annonces
Pas encore d’annonce pour ce modèle
Quand quelqu’un vendra un US-224, les annonces et l’historique des ventes s’afficheront ici.
Vendre le mêmeDescription
The US-224 combines a two-in, two-out audio interface, a 16-channel MIDI interface and a small control surface in one USB-powered unit. It records at up to 48 kHz and 24-bit resolution, and can also work at 16-bit. A guitar, microphone or keyboard can be plugged in directly.
The control surface has four faders, transport and locate controls and a data wheel, so mixer and transport functions in a DAW can be handled without the mouse. Mutes, solos and panning are covered too. The design follows the larger US-428, and the documentation lists a US-428 emulation mode and a control protocol document.
It connects to Mac and Windows computers over USB and draws its power from the bus, which suits laptop-based recording. Steinberg Cubase LE (48 audio tracks, 64 MIDI tracks) and the GigaStudio 3 LE 64-voice streaming sampler are bundled. Drivers were published for Windows 98 SE through Vista and for Mac OS 8.6 through OS X. The model has been discontinued and replaced by the US-2x2HR.
Vidéo
Spécifications
- Marque
- Tascam
- Modèle
- US-224
- Catégorie
- Studio › Interfaces audio
Audio
- Audio inputs
- 2
- Audio outputs
- 2
- Maximum resolution
- 24-bit
- Maximum sample rate
- 48 kHz
- Supported bit depths
- 16 or 24-bit
MIDI
- MIDI I/O
- 16-channel MIDI In/Out
Control Surface
- Faders
- 4
- Transport controls
- Transport/locate controls
- Data wheel
- Yes
- Other controls
- Mutes, solos, panning
Connectivity
- Computer connection
- USB
- Compatible platforms
- Mac and Windows
- Supported inputs
- Guitar, mic, keyboard
Power
- Power source
- Self-powered via USB
Software
- DAW software
- Steinberg Cubase LE (48 audio tracks, 64 MIDI tracks)
- Sampler software
- GigaStudio 3 LE (64-voice streaming sampler)
- Latest Windows driver
- v. 3.40 (Windows Vista and XP)
- Latest Mac driver
- v. 3.40 (OS X Universal Binary, Intel and PPC)
Status
- Availability
- Discontinued
- Replaced by
- US-2x2HR
